How to Change the Steering Shanks on Mini and Maxi Micro Scooters

Maintaining your scooter is essential for ensuring a smooth and safe ride. One of the key components that may need replacement over time is the steering shank. In this guide, we will walk you through the steps to change the steering shanks on both Mini and Maxi Micro scooters. While the process is similar for both models, there are a few differences to note, especially regarding the fender on the Maxi model.

Understanding the Components

Before diving into the process, it's important to familiarize yourself with the components involved in changing the steering shanks. Both the Mini and Maxi models have the following elements:

• Deck: The platform you stand on.
• Wheels: The parts that allow the scooter to move.
• Steering Shanks: The rods that connect the handlebars to the front wheel.
• Fender: A protective cover on the Maxi model that may need to be removed during the process.

Required Tools

To successfully change the steering shanks, you will need the following tools:

• 8mm socket spanner
• 4mm Allen key (x2)
• 12mm spanner
• Flathead screwdriver (optional)

Step-by-Step Guide to Changing Steering Shanks

Now that you have your tools ready, let’s go through the process step by step.

1. Remove the Deck

The first step involves removing the deck from the scooter. Each scooter has eight screws that need to be unscrewed:

• Two screws at the front
• Two screws in the middle
• Two screws at the back
• Two screws on the underside of the fender (for the Maxi model)

Once all screws are removed, gently lift the deck off.

2. Take Off the Wheels

Next, the wheels need to be removed. Use a 4mm Allen key for the axle bolts. Remember that the left-hand wheel has an anticlockwise thread. Unscrew the wheel bolts and set the wheels aside.

3. Access the Steering Shanks

With the deck and wheels removed, you can now access the steering shanks. Look for the two small nuts holding the shanks in place. Use an 8mm socket spanner to undo these nuts. After removing the nuts, you will need to use the 4mm Allen keys to unscrew the axle bolts located at the top and bottom of the shank.

4. Remove the Old Shanks

Once the nuts and bolts are removed, gently wiggle the shanks to remove them from the scooter. Be careful to not lose any small parts, such as the steering limiters or bushes that may come off with the shanks.

5. Install the New Shanks

Now it’s time to install the new steering shanks. Ensure that the steering limiters are positioned correctly with the cutouts facing outward. Place the shanks into the sockets and secure them with the axle bolts. Tighten the nuts using the 8mm socket spanner.

6. Reassemble the Scooter

After securing the new shanks, reassemble the scooter by following the steps in reverse order:

• Reattach the wheels, ensuring to follow the anticlockwise thread on the left wheel.
• Place the deck back on and screw in all eight screws.
• If you’re working on the Maxi model, reattach the fender before tightening the axle bolts.

Final Checks

Before taking your scooter for a ride, double-check that all screws and bolts are tight. Ensure that the steering moves freely and that everything is securely in place. This simple maintenance can significantly enhance your riding experience.

Conclusion

Changing the steering shanks on your Mini or Maxi Micro scooter is a straightforward process that can be done at home with the right tools and a little patience. Regular maintenance like this will keep your scooter in top shape and ensure a safe ride for years to come. If you encounter any issues, consult the manufacturer’s guidelines or seek professional assistance.
