How to Replace the Fender on a Maxi Micro Scooter
Replacing the fender on a Maxi Micro scooter is a straightforward task that can enhance the look and functionality of your scooter. Whether the fender is damaged, you want a change of color, or you need to access the B bends underneath, this guide will walk you through the process step by step.
Why Change the Fender?
There are several reasons you might want to change the fender on your Maxi Micro scooter:
- Damage: If your fender is scratched or damaged, replacing it can restore the scooter's appearance.
- Color Change: You may want to switch to a different color to personalize your scooter.
- Access to B Bends: Sometimes, you need to replace the B bends located under the fender.
Tools Needed
Before you begin, gather the following tools:
- 4mm Allen key
- Phillips screwdriver (if needed for other components)
Step-by-Step Guide to Remove the Fender
Follow these steps to successfully remove the fender from your Maxi Micro scooter:
1. Remove the Deck
The first step is to remove the deck of the scooter. There are a total of eight screws that need to be taken out:
- Two screws at the front
- Four screws in the center (these are longer)
- Two screws at the back
Make sure to keep track of which screws go where, as the longer screws must be placed back in their original positions.
2. Remove the Fender Bolts
Once the deck is off, you will see the fender bolts. There are two bolts you need to undo:
- These bolts have flat edges on either side, which will fit into recesses on the frame.
- Hold the bolts in place to prevent them from turning while you use the Allen key to loosen them.
3. Detach the Fender
After removing the bolts, gently lift the front of the fender to detach it from the scooter. This will also expose the B bends that sit underneath.
Replacing the B Bends
If you need to replace the B bends, you can do so at this point. Here’s how:
- Locate the two screws that hold the B bends in place.
- Remove these screws and take out the old B bends.
- Position the new B bends into the steering linkage and secure them with the screws.
Reinstalling the Fender
After you have replaced the B bends (if necessary), it’s time to put everything back together:
1. Position the Fender
Align the fender back onto the scooter, ensuring the bolts are properly seated in their respective positions.
2. Secure the Bolts
Insert the bolts back into the frame and tighten them carefully. Ensure that the flat ends are correctly positioned to hold the fender in place.
3. Reattach the Deck
Finally, reattach the deck, remembering the screw placements:
- Two short screws at the front
- Two long screws in the center
- Two short screws at the back
Final Check
After everything is back in place, give the scooter a quick shake to ensure that the fender and deck are securely attached. Your Maxi Micro scooter is now ready to ride with its new fender!
Conclusion
Changing the fender on your Maxi Micro scooter is a simple yet effective way to maintain its appearance and functionality. By following these steps, you can easily replace the fender and even access important components like the B bends. Enjoy your ride with your refreshed scooter!
